19" 33kW ORv3 Power Shelf
CPR-3331 Series

Home Products CPR-3331 Series

CPR-3331 Series

Peak Efficiency: 96.5%
Power Module:
- 5.5kW x 6 PSU (Minimum redundancy: N+1)
- Max output: 33kW (6+0) / 27.5kW (5+1)
- EDPP: 180%(500μs), 150%(50ms), 110%(60ms) -repeat over 10 seconds.
Peak Load Capability:
≤180% of rated power, ≤0.5ms
≤150% of rated power, ≤50ms
100% of rated power, continuous
Multiple Shelf Support (Shelf to Shelf):
- Power Shelf ↔ Power Shelf (Up to 8 shelves)
- Power Shelf ↔ BBU Shelf
One PMC with integrated BMC (ASPEED 2620) provides communication and connectivity for the power shelf, BBU shelf, power supplies, and BBU modules.
Highly accurate droop + active current sharing
Direct connection to tap-box / facility – no intermediate PDU

Datasheet

Download

Browse

BASIC SPECIFICATIONS
1RU Height, 19" Width 6 x 5.5kW PSU 1 x PMC with RJ45 Port 2 x Rear RJ45 Port 1 x AC Input
Dimensions	840 x 448 x 43.6 mm (D x W x H)
Warranty	3 Years

INPUT
Voltage	AC input: 200 - 277V L-N / 346 - 480V L-L(3W+N+PE)
Frequency	50 - 60Hz

ENVIRONMENTAL
Temperature	Operating : -5°C to 45°C Non-operating : -40 to 70°C
Altitude	Operating: 0 to 3,050 meters (10,000 feet) Non-operating: 0 to 10000 meters
Relative Humidity	Operating & Storage: 10% - 90% RH, non-condensing
